Schematic of Structural Layers

Overview:

This product is a specially modified elastic epoxy resin material for road and bridge paving. Thanks to proprietary epoxy resin toughening technology, it balances performance better than other products on the market, ensuring low deformation modulus, high elongation, and excellent adhesion to substrates. It is particularly suitable for anti-skid layer applications on road and bridge surfaces in environments with continuous vibration.

Applications:

Used as a bonding material for anti-skid layers on asphalt concrete, cement concrete, and steel bridge surfaces.

By adding pigments and scattering colored ceramic particles, the thin paving layer’s color can be altered, creating attractive anti-skid colored pavement.

Layered Structure Schematic:

Wear-resistant aggregate or ceramic particles (grain size ~3–5mm)

Waterproof anti-skid layer (~3mm thick)

Asphalt concrete base

Product Features:

Outstanding adhesion to substrates, perfectly bonding to asphalt concrete, cement concrete, and steel surfaces.

Firmly bonds ceramic particles and stones, ensuring they remain intact under continuous impact from vehicle wheels.

Excellent weather resistance ensures long-term durability under sunlight exposure.

Can be applied on slightly damp substrates without affecting adhesion.

Technical Specifications:

Application Method:

Milling the substrate to remove surface oils, slurry, dust, etc.

Weigh and mix components A and B in the specified ratio, or use 1 bucket of A to 1 bucket of B directly.

Add color pigments and filler powder to the mixed resin, and mix thoroughly.

Evenly spread the resin on the road and bridge surface, and sprinkle ceramic particles or stones, ensuring even coverage.

After the resin is mostly cured, sweep away excess ceramic particles or stones.

Traffic can be opened after the curing time is completed.

Precautions:

Ensure thorough and even mixing, paying attention to corners to avoid incomplete mixing. The mixed resin should have a uniform color.

Use the mixed resin promptly after preparation, especially when it begins to heat up, as this affects the working time.

At low temperatures, the material becomes more viscous. A hot air blower can be used on-site to reduce viscosity for easier application.

Transportation and Storage:

During storage and transportation, protect from rain, direct sunlight, packaging damage, and moisture.

Store in a cool, dry place, away from fire sources.

Shelf life is 24 months from the date of production.

This product is non-hazardous and can be transported as general goods.

Packaging Specifications:

20L metal drums or customized according to user requirements.

High flexibility and fatigue resistance ensure durability under continuous vibration on road and bridge surfaces.

Exceptional resistance to chemicals and abrasion.

Traffic can resume within 4–24 hours depending on the temperature.
